SWITCHES
IBS MULTI-SWITCH – SERIES IBS PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
MULTIPLE-STATION SWITCHES (continued)
IBS10B04106AR
TYPE I
0.388 (9.86) x 0.216 (5.49)
TYPE II
0.464 (11.79) x 0.288 (7.32)
PART NUMBERS/0.394" (10MM) CENTERS 1
Interlock
? IBS10B02106AR
? IBS10B04106AR
? IBS10B06106AR
? IBS10B08106AR
Number of Stations 2
2
4
6
8
IBS MULTI-SWITCH SWITCHES
SERIES IBS
Series IBS miniature pushbutton switches are mounted on common
? IBS10B10106AR
? IBS10B12106AR
10
12
frames, up to 12 stations long with center-to-center spacing of
0.394" (10mm), 0.590" (15mm) or 0.787" (20mm). Available with
PART NUMBERS/0.590" (15MM) CENTERS 1
interlock, non-lock (momentary) or push-lock/push-release
mechanical functions. .130" (3.30mm) x .130" (3.30mm) square
plungers accept a full line of industry standard pushbuttons.
Switches are stocked without pushbuttons due to wide variety
that can be used. Order pushbuttons separately. Switches have
.157" (4mm) long PC terminals for mounting single- or double-
? IBS15B02106AR
? IBS15B04106AR
? IBS15B06106AR
? IBS15B08106AR
? IBS15B10106AR
? IBS15B12106AR
2
4
6
8
10
12
sided PC boards up to .094" (2.39mm) thick. Close stacking
(centers) permits high density within minimum front panel space.
PART NUMBERS/0.787" (20MM) CENTERS 1
PUSHBUTTONS
Pushbuttons designed for IBS switches are available in white,
black, red, blue and gray. Others colors are available on special
order. Pushbutton faces are concave for operator convenience
and can be mounted either horizontally or vertically.
Pushbuttons must be ordered separately, but may be factory
? IBS20B02106AR
? IBS20B04106AR
? IBS20B06106AR
? IBS20B08106AR
? IBS20B10106AR
? IBS20B12106AR
2
4
6
8
10
12
installed, if desired, at nominal extra cost.
SPECIFICATIONS
MECHANICAL
Switch Actuation: Momentary, interlock and push-lock/
push-release.
1. Switches with all-lock function are available on special order.
Contact Switchcraft.
2. Odd number of stations (3, 5, 7, 9, 11) are available. Switches with
13 through 18 stations also available. Contact Switchcraft.
? Special order only; Contact Switchcraft for price and delivery information.
PUSHBUTTON PART NUMBERS
Plunger Travel: .144" (3.66 mm).
Actuation Force: At .135" (3.43mm) travel: 12-15 oz.
ELECTRICAL
0.125A resistive @ 125 V AC, .25 AMP at 28V DC.
MATERIALS
Housing: Thermoplastic 94V-0.
Plunger: Thermoplastic UL 94V-0.
Contactors: Copper alloy.
Terminals: Copper alloy, solder plated. Tin-dipped
available on special order.
Contact Surfaces: Plated.
Frame: Copper alloy.
Type I
P2936
P2937
P2938
? P2939
? P2940
P2941
P2942
? P2943
-
-
Type II
P2951
P2952
P2953
? P2954
? P2955
P2956
P2957
? P2958
? P2979
? P2992
Color
White
Black
Red
Yellow
Green
Blue
Gray
Brown
Cream
Tangerine
Latch Bar: Thermoplastic.
? Available on special order only; contact Switchcraft for price and delivery.
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
